汽车后桥异形后盖五轴数控自动焊接专机特点介绍

来源:http://www.tayfsk.com/  发布时间:2024-03-29 浏览次数:0

主要用途:

Main use:

该焊接专机主要应用于汽车后桥异形后盖角环缝的自动化焊接。

This welding machine is mainly used for automated welding of corner and circumferential seams on irregular rear covers of automotive rear axles.

主要优点:

Main advantages:

稳定焊接质量,保证其一致性;

Stable welding quality to ensure consistency;

改善工人劳动条件,降低对工人操作技术的要求;

Improve the working conditions of workers and reduce the requirements for their operational skills;

提高产量,增加企业效益;

Increase production and increase enterprise efficiency;

性价比较高;

High cost performance ratio;

设备主要配置:

Main equipment configuration:


采用高质量5轴数控系统集成控制,减少设备故障率;

Adopting high-quality 5-axis CNC system integrated control to reduce equipment failure rate;

采用sansung系列的s3c2410a 单片机(arm9)主频高达200mhz;

Adopting the Sansung series s3c2410a microcontroller (arm9) with a main frequency of up to 200MHz;

采用进口伺服电机无极调速,保证设备运行轨迹精度,增加设备的使用寿命;

Adopting imported servo motors for stepless speed regulation to ensure the accuracy of equipment operation trajectory and increase the service life of the equipment;

采用10.4寸彩色触摸屏为界面输入,更便于操作和参数调整;

Using a 10.4-inch color touch screen as the interface input for easier operation and parameter adjustment;

任意5轴直线插补、圆弧插补;采用示教编程方式;

Arbitrary 5-axis linear interpolation and circular interpolation; Using demonstration programming method;

结构介绍:

Structure introduction:

该焊接专机由立式焊接机床、两轴变位机、焊接电源、送丝机构、焊枪(可选空冷或水冷)及电气控制等部分组成。

This welding machine consists of a vertical welding machine, a two axis displacement machine, a welding power supply, a wire feeding mechanism, a welding gun (optional air or water cooling), and electrical control.

该焊接专机为单机头结构类型,焊接方式采用工件旋转、变位与焊枪相互协调运行的方式;焊接工件直径和长度根据用户需要设计。

The welding machine is a single head structure type, and the welding method adopts the coordinated operation of workpiece rotation, displacement, and welding gun; The diameter and length of the welded workpiece are designed according to user needs.

该焊接专机具有可长期进行焊接作业、保证焊接作业的高生产率、高质量和高稳定性等特点。

This welding machine has the characteristics of being able to perform welding operations for a long time, ensuring high productivity, high quality, and high stability of welding operations.
