焊接变位机在使用中要特别注意保养，尤其是对其中的焊接卡盘的保养，卡盘的作用很大，所以一定不要忘记对它的维护工作，另外，还要做好对设备结构的检验工作，山东自动焊接设备厂家接下来为大家一一分析一下。

Special attention should be paid to the maintenance of the welding positioner in use, especially the maintenance of the welding chuck. The chuck plays a very important role, so we must not forget to maintain it. In addition, we should also do a good job in the inspection of the equipment structure. The Shandong automatic welding equipment manufacturer will analyze it one by one.

1、在卡盘使用完成后，一定要用风枪等工具对卡盘本体以及滑道表面进行清洁，这样可以保证卡盘长时间使用之后，仍具有良好的精度，所以对卡盘的定期润滑工作很重要。

1. After the chuck is used, the chuck body and slide surface must be cleaned with tools such as an air gun, which can ensure that the chuck still has good accuracy after a long time of use, so regular lubrication of the chuck is very important.

2、每天少打一次二硫化钼油脂(颜色为黑色)，将油脂打入卡盘油嘴内，直到油脂溢出夹爪面或卡盘内孔处(内孔保护套与连结螺帽处)。

2. Apply molybdenum disulfide grease (black in color) at least once a day, and inject the grease into the chuck nozzle until the grease overflows the jaw face or the inner hole of the chuck (the inner hole protective sleeve and the connecting nut).

3、为防止卡盘内部生锈，加持力降低，无法夹紧工件，因此尽量使用具有防锈效果的切削油，使用切削油可以预防卡盘内部生锈。

3. In order to prevent the chuck from rusting inside, the holding force is reduced, and the workpiece cannot be clamped, so try to use cutting oil with anti rust effect. The use of cutting oil can prevent the chuck from rusting inside.

4、作业完成时一定要以风枪或类似工具，来清洁卡盘本体及滑道面。

4. When the operation is completed, air gun or similar tools must be used to clean the chuck body and slide surface.

5、焊接卡盘少每过6个月拆下清洗，保持夹爪滑动面干净并给予润滑，使卡盘寿命增长。

5. The welding chuck shall be disassembled and cleaned at least every 6 months to keep the sliding surface of the jaw clean and lubricated, so as to increase the service life of the chuck.

6、检查各零部件有无破裂及磨损的情况，削铸铁少每2个月一次来清洁，如遇严重有损零件应立刻换个新品。

6. Check whether all parts are cracked and worn. Clean the cast iron at least once every 2 months. In case of serious damage, replace it with a new one immediately.

7、针对不同工件一定要使用不同夹持方式，若是使用它去夹不规则工件会造成卡盘损坏。

7. Different clamping methods must be used for different workpieces. If it is used to clamp irregular workpieces, the chuck will be damaged.

8、当卡盘压力不正常时，让卡盘处于高压力下将工件夹住，这将会降低卡盘使用寿命，所以当发现卡盘间隙过大时一定要立即换一个新的卡盘。

8. When the chuck pressure is abnormal, let the chuck clamp the workpiece under high pressure, which will reduce the service life of the chuck. Therefore, when it is found that the chuck clearance is too large, a new chuck must be replaced immediately.

卡盘的保养方法基本上就是以上八点内容，为了延长焊接变位机的使用寿命，就要在平时做好检查保养工作，尤其是对卡盘的保养，另外一旦出现问题也要及时进行维修，以免影响使用。更多相关内容就来我们网站http://www.tayfsk.com进行咨询了解！

The maintenance method of the chuck is basically the above eight points. In order to prolong the service life of the welding positioner, it is necessary to do a good job of inspection and maintenance at ordinary times, especially the maintenance of the chuck. In addition, once there is a problem, it is also necessary to timely repair, so as not to affect the use. More relevant content will come to our website http://www.tayfsk.com Ask about it!
